I have a report that renders images (jpg) that have been collected from various sources. This works fine within the report viewer, and when exporting via Excel.
However, when exporting to PDF, about 5% of the images are rendered incorrectly as can be seen below, with the original on the left, and what is rendered on the right;
I find that if I open up one of these images in mspaint, and just click save, on the next report-run the image is now rendered correctly.
Are there any rules as to what image properties/format are valid for SSRS to render the image correctly within a PDF? Essentially I'd like to somehow find these images that will render incorrectly before the report is run and fix them prior..
4 Answers
Because of the way the output looks I would say those JPEG images have CMYK colorspace but the SSRS assumes they use RGB colorspace and sets the wrong colorspace in PDF.
If you can post a JPEG image and a sample PDF I can give you more details.
Mihai IancuMihai IancuI never ended up getting SSRS to display the the problem images as they were, however, determining before running the report which images would be included in the non-displayable set so they could be converted to a supported format (automatically) was also a solution.
In my case, all images were supplied via users uploading to a website, so I was able to identify and convert images as they arrived. For all existing images, I was able to run a script that identified the problem images and convert them.
Identifying problem images
From the thousands of images I had, I was able to determine that the images that wouldn't render correctly had the following properties:
- Image had CMYK colorspace or;
- Image had extended color profiles or;
- Both of the above
Converting an image
I was originally using the standard .NET GDI (System.Drawing) to manipulate images however the API is often prone to crashes (OutOfMemoryException) when dealing with images that have extra data. As such, I switched to using ImageMagick where for each of the identified images I:
- Stripped the color profiles and;
- Converted to RGB
Note that the conversion to RGB from CMYK without stripping the color profiles was not enough to get all images to render properly.
Pdf Rendering Software
I ended up just doing those items on every image byte stream I received from users (without first identifying the problem) before saving an uploaded image to disk. After which, I never had the rendering problem again.
Stafford WilliamsStafford WilliamsI've had exactly the same problem with an image rendering correctly on screen but appearing like the one in the question when I exported the report to PDF. Here's how I solved it.
The Problem
The first clue was this article I came across on MSDN. It seems that regardless of the original image density, the PDF renderer in SSRS resizes all images to 96 DPI. If the original size of the image is larger than the size of the page (or container), then you will get this problem.
The Solution
Hp 990c driver download windows 10. The solution is to resize the source image such that it will fit on your page. The requires a little calculation depending on your page size and margin settings.
In my case, I'm using A4 paper size, which is 21cm by 29.7cm. However, my left margin is 1.5cm, and my right margin is 0.5cm, for a total inner width of 19cm. I allow an extra 0.5 cm as a margin of error, so I use an inner width of 18.5cm.
As noted before, the resolution generated by the PDF renderer is 96 DPI (dots per inch). For those of us not in the United States or Republic of Liberia, that's 37.79 DPC (dots per centimetre). So, to get our width:
Your result may be different depending on (1) the paper size you are using, and (2) the left and right margins.
As the page is higher than it is wide, we need only resize the width while keeping the image proportional. If you're using a paper size which is wider than it is tall, you'd use the length instead.
ELM327 Drivers need to be properly installed in order for your device to work with your computer. If the drivers are not installed properly you will have trouble communication with your device. In most instances when connecting the ELM327 to your computer (via USB, Bluetooth or WiFi) the drivers should automatically install. Jan 29, 2013 ELM327 USB: Windows Installation Driver Files. Posted by - NA - on 29 January 2013 01:20 AM. Click here for complete step-by-step guide, including driver files for correctly installing your ELM327 USB cable interface (or Bluetooth) to Windows. Supports both Clone China ELM327's and genuine ELM327's by ElmElectronics. If you bought ELM327 cable from elsewhere (clones, eBay, other manufacturers) then install all Driver Packs below, because they cover widest range of chip makers. DRIVER PACK 1 Steps to install Driver Pack 1: If you have 64-bit Windows, double-click on: CP210xVCPInstallerx64; If you have 32-bit Windows, double-click on: CP210xVCPInstallerx86. 36 rows Jul 18, 2016 Elm327 Usb Interface Driver for Windows 7 32 bit, Windows 7 64 bit, Windows. For ELM327 USB Scanners with the CH340 Serial to USB Chip. If the FTDI, Silicon Labs or Prolific USB drivers do not work for your scanner, it's most likely you need this driver Windows CH340 USB to Serial Driver: Link 1: For Windows XP/7/8.1/10 (32/64 bit) Mac OS CH340 USB to Serial Driver: Link 1: Supports 32/64 bit: Linux CH340 USB to Serial Driver: Link 1. Drivers for elm327.
So now open the source image in Paint (or your image editor of choice), and proportionally resize the image to the desired width (or length) in pixels, save it, import it into your container, and size the image visually with respect to the container. It should look the same on screen, and now render correctly to PDF.
Mark MicallefMark MicallefThis is an issue reported to Microsoft Connect.
From SSRS 2008 How to get the best image quality possible?:
Overleaf Pdf Rendering Error
The image behavior you see in PDF is a result of some image conversions that the PDF renderer does, based on how the PDF specification requires that serialize images into PDF.
Naruto gamecube rom. Nintendo GameCubeIndigo GameCube andManufacturerNintendoGenerationSixth generationRetail availabilitySeptember 14, 2001November 18, 2001May 3, 2002May 17, 2002Discontinued2007Units soldWorldwide: 21.74 millionJapan: 4.04 millionNorth America: 12.94 millionEurope & Australia: 4.77 millionMediaNintendo GameCube Game DiscCPUIBM PowerPC 'Gekko', 486MHzStorage capacityNintendo GameCube Memory Card (16MB max.
We know it's not ideal, and we classify the loss of image quality as a product issue. Therefore, it's difficult to really say what to do to get the best quality image.
Anecdotally, I have heard that customers have good results when the original image is a BMP
